Rear Panel Components (Service)
No. Description Links
13 Drives 0 to 5 (numbered bottom to top) “Servicing Drives” on page 69
Related Information
■
“Rear Panel Components (Service)” on page 15
■
“Rear Panel Components (Service)” on page 15
■
“Motherboard Component Locations” on page 21
■
“I/O Component Locations” on page 22
■
“Power Distribution and Fan Module Component Locations” on page 24
■
“System Schematic” on page 25
Rear Panel Components (Service)
No. Description Links
1 Power supply 0 status indicator LEDs “Servicing Power Supplies” on page 89
2 Power supply 0 AC inlet
3 Power supply 1 status indicator LEDs “Servicing Power Supplies” on page 89
4 Power supply 1 AC inlet
5 Server status LEDs “Rear Panel Controls and LEDs” on page 39
Identifying Components 15
