Release the CMA
Squeeze the green slide release latches to release the slide rails.
3.
While squeezing the slide release latches, slowly pull the server forward until the
slide rails latch.
Related Information
■
“Release the CMA” on page 64
■
“Remove the Server From the Rack” on page 66
Release the CMA
For some service procedures, such as replacing a power supply, if you are using a CMA, you
might need to release the CMA to gain access to the rear of the chassis.
Note - For instructions on how to install the CMA for the first time, refer to Server Installation.
64 SPARC T5-2 Server Service Manual • February 2017
