Page #29 background image
Component Task Reference
Component Oracle ILOM Target Links
/SYS/FANBD/F4 (center rear)
/SYS/FANBD/F5 (right rear)
Front control panel light pipe
assembly
N/A “Servicing the Drive
Backplane” on page 157
Memory risers
/SYS/MB/CM0/CMP/MR0
/SYS/MB/CM0/CMP/MR1
/SYS/MB/CM0/CMP/MR2
/SYS/MB/CM0/CMP/MR3
/SYS/MB/CM1/CMP/MR0*
/SYS/MB/CM1/CMP/MR1*
/SYS/MB/CM1/CMP/MR2*
/SYS/MB/CM1/CMP/MR3*
“Servicing Memory Risers and
DIMMs” on page 97
Motherboard
/SYS/MB
“Servicing the
Motherboard” on page 141
PCIe card (in slot 1)
/SYS/MB/PCIE1
/SYS/MB/PCIE2
/SYS/MB/PCIE3
/SYS/MB/PCIE4
/SYS/MB/PCIE5
/SYS/MB/PCIE6
/SYS/MB/PCIE7
/SYS/MB/PCIE8
“Servicing PCIe
Cards” on page 121
Power supplies
/SYS/PS0 (outer)
/SYS/PS1 (inner)
“Servicing Power
Supplies” on page 89
PS backplane and cover
/SYS/PDB
“Servicing the PS
Backplane” on page 163
SP
/SYS/MB/SP
“Servicing the SP” on page 129
Related Information
“Component Service Categories” on page 57
“Internal Component Locations” on page 17
“Motherboard Component Locations” on page 21
