Internal Component Locations
No. Component Oracle ILOM Target Links
/SYS/PS1 (inner)
4 PS backplane and cover
/SYS/PDB
“Servicing the PS
Backplane” on page 163
5 Drive backplane
/SYS/SASBP
“Servicing the Drive
Backplane” on page 157
6 Motherboard
/SYS/MB
“Servicing the
Motherboard” on page 141
7 Battery
/SYS/MB/BAT
“Servicing the Battery” on page 117
8 Processor modules and heat sinks (these
are only replaceable by replacing the
motherboard)
* This processor module is not present on
the 1-processor server
/SYS/MB/CM0
/SYS/MB/CM1*
“Servicing the
Motherboard” on page 141
9 Memory risers
* These memory risers are not present in
the 1-processor server
/SYS/MB/CM0/CMP/MR0
/SYS/MB/CM0/CMP/MR1
/SYS/MB/CM0/CMP/MR2
/SYS/MB/CM0/CMP/MR3
/SYS/MB/CM1/CMP/MR0*
/SYS/MB/CM1/CMP/MR1*
/SYS/MB/CM1/CMP/MR2*
/SYS/MB/CM1/CMP/MR3*
“Servicing Memory Risers and
DIMMs” on page 97
10 Fan board
/SYS/FANBD
“Servicing the Fan Board” on page 135
11 Fan modules As viewed from front of server:
/SYS/FANBD/F0 (left front)
/SYS/FANBD/F1 (center front)
/SYS/FANBD/F2 (right front)
/SYS/FANBD/F3 (left rear)
/SYS/FANBD/F4 (center rear)
/SYS/FANBD/F5 (right rear)
“Servicing Fan Modules” on page 81
12 DVD drive
/SYS/SASBP/DVD
“Servicing the DVD
Drive” on page 113
13 Drives
/SYS/SASBP/HDD0 (bottom)
/SYS/SASBP/HDD1
/SYS/SASBP/HDD2
“Servicing Drives” on page 69
Identifying Components 19
