10.2 A List of Status Messages
Status
type
Status
(Status display)
Description
Indications in error Influences on output in an error
RED
LED
GRN
LED
Backlight
（※1）
Analog
Output 1
Analog
Output 2
Pulse
Output 1
Pulse
Output 2
Status
Output
Fixed Output
Analog Output 1 Fixed (Ana. Out 1 Fix)
Analog output 1 fixed is active (※2)
OFF Blink OFF
Fixed output Unaffected
Unaffected
Unaffected
Analog Output 2 Fixed (Ana. Out 2 Fix)
Analog output 2 fixed is active (※2) Unaffected Fixed output
Pulse Output 1 Fixed (Pls. Out 1 Fix)
Pulse output 1 fixed is active (※2)
Unaffected
Fixed output Unaffected
Pulse Output 2 Fixed (Pls. Out 2 Fix)
Pulse output 2 fixed is active (※2) Unaffected Fixed output
Status Output Fixed (Status Out Fix)
Status output fixed is active (※2) Unaffected Unaffected Fixed output
0% Sig Lock (0% Sig Lock)
With a status input, 0% signal lock is active. (※2) (Analog output clamped at 4mA with no pulse output.)
4mA Stopped Unaffected
Calibration
in Progress
Calibration in Progress (Cal. in Progress)
Auto zero in progress OFF Blink
OFF while ORG indicator blinks at operation startup and shutoff. OFF during the test
Unaffected Unaffected Unaffected
H/L Alarm
H/L Alarm Triggered (H/L Alm. Trig.)
H/L alarm occurred and is active. (For details, see 9.16 High/Low Alarm Function.)
OFF Blink OFF Unaffected Unaffected Unaffected
Drive Out
Alarm
Drive Out Alarm (Drive Out Alarm)
Drive output is exceeds the threshold. OFF Blink OFF Unaffected Unaffected Unaffected
Test
Self Diagnosis (Self-Diag)
Self diagnosis in progress OFF Blink OFF 0％ Stopped Unaffected
Installation (Installation)
Pipeline vibration check in progress OFF Blink OFF 0％ Stopped Unaffected
Maintenance Test (Maintenance Test)
Maintenance in progress OFF Blink OFF
Unaffected
(Set output during simulated output)
Unaffected
(Set output during simulated output)
Unaffected
(Set output
during simulated
output)
Transmitter
Operation
Key Protect (Key protect.)
If parameter change is made by switch operation while the Key Protect was ON. (If key operation is required, reconfiguration is needed.)
OFF ON OFF Unaffected Unaffected Unaffected
Write protect.
When the target parameter is changed or the operation for executing the target function is carried out in Write Protect mode.
OFF ON OFF Unaffected Unaffected Unaffected
Xmtr Operating-Time Over ("○" blinks at lower left of LCD)
When the number of run hours has exceeded 100,000 hours, it could lead to component failure or degradation. We suggest transmitter replacement. (You can cancel indicator ○. See 9.2.7 Transition chart (6) [No. 4-3].)
OFF ON OFF Unaffected Unaffected Unaffected
Xmtr Warm up (WARMUP 20)
Warmup in progress (Stays on for 20 minutes upon power on. Countdown value decrements at one (1) minute intervals.)
OFF ON OFF Unaffected Unaffected Unaffected
Power OK ?
Poor power supply condition is a possibility. (A short duration power cycling has occurred a couple of times.) While there is no problem in continuation of operation, we suggest to run a check for condition of power supply. This message goes out automatically in 20 minutes.
OFF ON OFF Unaffected Unaffected Unaffected
※1: Even with the run indicator staying off, the white backlight comes on in response to switch operation if backlight is set in the sleep mode. ※2: Simulated output is available irrespective of the state of alarm. (Certain types of error disables output, however.)
