14. PRODUCT CODE EXPLANATION
14.1 Type U
●
Main code (CA00A to CA080)
○ :
Compatible,
× : Not
applicable,
△ :
Request inquiries
① ②
Model Selector Chart
C A ALTImass Type U
CA00A, CA001
CA003 CA006 CA010 CA015 CA025
CA040, CA050
CA080
High temp. service: CA025, CA040, CA050
High temp. service: CA080
Low temp. explosionproof service: CA025, CA040, CA050, CA080
③ ④ ⑤
Meter size/Nominal Diameter
JIS Flange ASME·JPI Flange DIN Flange Ferrule Screw
0 0 A R1/4
0 0 1 R1/4
0 0 3 10mm 1/2˝ DN 15 10A Rc3/8
0 0 6 10mm 1/2˝ DN 15 10A Rc3/8
0 1 0 15mm 1/2˝ DN 15 15A Rc3/8
0 1 5
15mm 1/2˝ DN 15 15A Rc3/4
25mm 1˝ DN 25
0 2 5
25mm 1˝ DN 25 25 (ISO), IDF 1S
40mm 1˝·1/2˝ DN 40
0 4 0 40mm 1˝·1/2˝ DN 40 38 (ISO), IDF 1.5S
0 5 0 50mm 2˝ DN 50 51 (ISO), IDF 2S
0 8 0
80mm 3˝ DN 80 76.1 (ISO), IDF 3S
100mm 4˝ DN 100
⑥ —
⑦
Fluid category
L Liquid
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
G Gas
○ ○ ○ ○ ○ ○ ○ ○ × × ○
⑧
Temp. category ※1
2 Standard (200℃ and lower)
○ ○ ○ ○ ○ ○ ○ ○ × × ×
3 High temp. (350℃ and lower)
× × × × × × × × ○ ○ ×
4 Low temp. explosionproof (−200℃ to +50℃)
× × × × × × × × × × ○
⑨
Major parts material
S SUS316L
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
M SUS316L+Alloy C
× ○ ○ ○ ○ ○ ○ ○ × ○ ○
H Alloy C ※2
× ○ ○ ○ ○ ○ ○ ○ × ○ ○
P Alloy C (High Pressure) ※3
× × × ○ ○ × × × × × ×
⑩ ⑪
Process connection
J 1 JIS10K (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
J 2 JIS20K (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
J 3 JIS30K (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
J 4 JIS40K (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
J 6 JIS63K (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
A 1 ASME150 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
A 3 ASME300 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
A 6 ASME600 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
P 1 JPI150 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
P 3 JPI300 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
P 6 JPI600 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
D 1 DIN PN10 ※4 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
D B DIN PN16 ※4 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
D 3 DIN PN25 ※4 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
D 4 DIN PN40 ※4 (Standard nominal size ※9)
× ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
K 1 JIS10K (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
K 2 JIS20K (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
K 3 JIS30K (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
B 1 ASME150 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
B 3 ASME300 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
B 6 ASME600 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
Q 1 JPI150 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
Q 3 JPI300 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
Q 6 JPI600 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
E 1 DIN PN10 ※4 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
E B DIN PN16 ※4 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
E 3 DIN PN25 ※4 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
E 4 DIN PN40 ※4 (Expanded nominal size ※10, ※11)
× × × × △ △ × ○ × × ×
T T Screw (Male)
○ × × × × × × × × × ×
T C Screw (Female)
× ○ ○ ○ ○ × × × × × ×
H S ISO Ferrule
× ○ ○ ○ ○ ○ ○ ○ × × ×
Z 9 Special
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
※1: Explosionproof specications are restricted depending on the temp. class.
※2: When "H" is chosen for "Major parts material
⑨
", CA003 are always threaded connection,
and CA006 to CA080 are loose ange type.
※3: When "P" for high pressure is chosen as "Major parts material
⑨
", threaded connection is always applied.
※4: DIN ange is applied only when "S" and "M" are chosen for "Major parts material
⑨
".
※5: "2, 3" for "Communication protocol
󰼼
" are not applicable.
※6: CRN is applicable only to CSA explosionproof and ASME ange models.
※7: When selecting "B" for "Regulations
⑮
" following limitations apply:
Code
③④⑤
are only to size 040, 050 and 080.
Code
⑨
is only to S.
Code
⑩⑪
are only to A1, A3, A6, D1, DB, D3 and D4.
※8: The maximum measurement temperature of integral type is 150℃.
"High temp. and low temp. type CA00A to CA003" are only "(transmitter) separate type".
⑫ —
⑬
Explosionproof
0 Non-explosionproof
1 TIIS
2 ATEX, IECEx
3 KCs
4 CSA (C-US)
5 EAC
7 NEPSI ※5
T ITRI
⑭
Ex-proof temp. class
0 Non-explosionproof
1 T1
2 T2
3 T3
4 T4
5 T5
⑮
Regulations
0 Standard
G
High Pressure Gas Safety Act
(Approved product)
w/Material test certicate
H
High Pressure Gas Safety Act
(Individual test)
w/Material test certicate
J
High Pressure Gas Safety Act
(Completion inspection)
w/Material test certicate
M Gas Business Act w/Material test certicate
T Fire Service Act w/Material test certicate
S Ship Classication Society Pattern Approval Separately mounted only
P
Ship Classication Society Pattern Approval + w/Material test certicate
Separately mounted only
C CRN (Canadian Registration Number) Pattern approval ※6
K
CRN (Canadian Registration Number) Pattern approval
+ w/Material test certicate ※6
F w/Material test certicate
B PED ※7
⑯ —
⑰
Transmitter
1 ALTImass
⑱
Transmitter construction ※8
1 Integrally mounted
2 Separately mounted
⑲
Power source
1 20 to 30VDC
2 85 to 264VAC (safety rating: 100 to 240VAC) 50/60Hz
⑳
Pulse
0 When "2, 3" are chosen for "Communication interface
󰼼
"
B Voltage
G Open drain (open collector output equivalent) (Standard)
󰼼
Communication protocol
1 HART communication (HART protocol version 7, Bell202)
2 FOUNDATION Fieldbus H1 communication (ITK version6)
3 PROFIBUS PA communication (Prole version3.02)
4 Modbus communication (RS-485 Modbus protocol)
󰽇
Version code
A Version code: A (CA003 only)
B Version code: B
󰽈
—
󰽉
Special shape designation
0 Standard
Z Special shape (including polishing, long neck)
※9: The standard nominal size of each model is as follows.
Model JIS Flange ASME•JPI Flange DIN Flange
CA003 10mm 1/2″ DIN15
CA006 10mm 1/2″ DIN15
CA010 15mm 1/2″ DIN15
CA015 15mm 1/2″ DIN15
CA025 25mm 1″ DIN25
CA040 40mm 1·1/2″ DIN40
CA050 50mm 2″ DIN50
CA080 80mm 3″ DIN80
※10: The expanded nominal size of each model is as follows.
Model JIS Flange ASME•JPI Flange DIN Flange
CA015 ( Request inquiries ) 25mm 1″ DIN25
CA025 ( Request inquiries ) 40mm 1·1/2″ DIN40
CA080 100mm 4″ DIN100
※11: Expanded nominal size is applied only when "S" and "M" are chosen for
"Major parts material
⑨
".
⑧⑦−⑤④③②① −⑮⑭⑬−⑪⑩⑨ ⑰ ㉒㉑⑳⑲⑱
Model
Process connection
Temp. category
Fluid category
Meter size/Nominal Diameter
Major parts material
Power source
Transmitter construction
Version code
Special shape designation
Communication protocol
Pulse
Transmitter
Regulations
Explosionproof
Ex-proof temp. class
Main code
/ / / Additional code
− ㉔
