Oval ALTI mass CA00A - Page 146

L
--
740
--
28
--
E
1
●
Main code (CA100 to CA250)
① ②
Model
C A ALTImass Type U
CA100, CA150,
CA15H, CA200,
CA20H, CA250
High temp. service:
CA100, CA150
Low temp. explosionproof service:
CA100, CA150,
CA15H, CA200, CA20H, CA250
③ ④ ⑤
Meter size/Nominal Diameter
JIS Flange ASME·JPI Flange DIN Flange
1 0 0 100mm 4˝ DN 100
1 5 0 150mm 6˝ DN 150
1 5 H 150mm 6˝ DN 150
2 0 0 200mm 8˝ DN 200
2 0 H 200mm 8˝ DN 200
2 5 0 250mm 10˝ DN 250
⑥ —
⑦
Fluid category
L Liquid
○ ○ ○
⑧
Temp. category ※1
2 Standard (200℃ and lower)
○ × ×
3 High temp. (350℃ and lower)
× ○ ×
4 Low temp. explosionproof (−200℃ to +50℃)
× × ○
⑨
Major parts material
S SUS316L
○ ○ ○
⑩ ⑪
Process connection
J 1 JIS10K
○ ○ ○
J 2 JIS20K
○ ○ ○
J 3 JIS30K
○ ○ ○
A 1 ASME150
○ ○ ○
A 3 ASME300
○ ○ ○
A 6 ASME600
○ ○ ○
P 1 JPI150
○ ○ ○
P 3 JPI300
○ ○ ○
P 6 JPI600
○ ○ ○
D 1 DIN PN10
○ ○ ○
D B DIN PN16
○ ○ ○
D 3 DIN PN25
○ ○ ○
D 4 DIN PN40
○ ○ ○
Z 9 Special
○ ○ ○
※1: Explosionproof specications are restricted depending on the temp. class.
※2: "2, 3" for "Communication protocol
󰼼
" are not applicable.
※3: CRN is applicable only to CSA explosionproof and ASME ange models.
※4: When selecting "B" for "Regulations
⑮
" following limitations apply:
Code
⑩⑪
are only to A1, A3, A6, D1, DB, D3 and D4.
※5: When selecting explosionproof other than TIIS with uid temperature exceeding 80℃, only "(transmitter)
separate type" is applicable.
"High temp. and low temp. type" can only be "(transmitter) separate type".
⑫ —
⑬
Explosion-proof
0 Non-explosionproof
1 TIIS
2 ATEX, IECEx
3 KCs
4 CSA (C-US)
5 EAC
7 NEPSI ※2
T ITRI
⑭
Ex-proof temp. class
0 Non-explosionproof
1 T1
2 T2
3 T3
4 T4
5 T5
⑮
Regulations
0 Standard
G
High Pressure Gas Safety Act
(Approved product) CA100 and CA150 only
※w/Material test certicate
H
High Pressure Gas Safety Act
(Individual test)
※w/Material test certicate
J
High Pressure Gas Safety Act
(Completion inspection)
※w/Material test certicate
M Gas Business Act ※w/Material test certicate
T Fire Service Act ※w/Material test certicate
S Ship Classication Society Pattern Approval
P
Ship Classication Society Pattern Approval
+ w/Material test certicate
C CRN (Canadian Registration Number) Pattern approval ※3
K
CRN (Canadian Registration Number) Pattern approval
+ w/Material test certicate ※3
F w/Material test certicate
B PED ※4
⑯ —
⑰
Transmitter
1 ALTImass
⑱
Transmitter construction ※5
1 Integrally mounted
2 Separately mounted
⑲
Power source
1 20 to 30VDC
2 85 to 264VAC (safety rating: 100 to 240VAC) 50/60Hz
⑳
Pulse
0 When "2, 3" are chosen for "Communication interface
󰼼
"
B Voltage
G Open drain (open collector output equivalent) (Standard)
󰼼
Communication protocol
1 HART communication (HART protocol version 7, Bell202)
2 FOUNDATION Fieldbus H1 communication (ITK version6)
3 PROFIBUS PA communication (Prole version3.02)
4 Modbus communication (RS-485 Modbus protocol)
󰽇
Version code
B Version code: B
󰽈
—
󰽉
Special shape designation
0 Standard
Z Special shape
⑧⑦−⑤④③②① −⑮⑭⑬−⑪⑩⑨ ⑰ ㉒㉑⑳⑲⑱
Model
Process connection
Temp. category
Fluid category
Meter size/Nominal Diameter
Major parts material
Power source
Transmitter construction
Version code
Special shape designation
Communication protocol
Pulse
Transmitter
Regulations
Explosionproof
Ex-proof temp. class
Main code
/ / / Additional code
− ㉔
