Oval ALTI mass CA00A - CA100 to CA250

L
--
740
--
28
--
E
1
Item
Product Code
Description
Selector Chart
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱
Model C A
ALTImass Type U
CA100, CA150
C
A15H, CA200, CA20H, CA250
H
igh temp. service:
C
A100, CA150 (below 350℃)
Low temp. explosionproof service:
C
A100,CA150,CA15H,CA200,CA20H,CA250
Nominal
size
1 0 0
100mm connection (4˝)
1 5 0
150mm connection (6˝)
1 5 H
150mm connection (6˝)
2 0 0
200mm connection (8˝)
2 0 H
200mm connection (8˝)
2 5 0
250mm connection (10˝)
Fluid category L
Liquid service
○ ○ ○
2
Standard (below 200°C)
○ × ×
3
High temperature service (below 350°C)
× ○ ×
4
Low temperature explosionproof service (－200°C to ＋50℃)
× × ○
Pressure category 1
Standard
○ ○ ○
Major parts material S
SUS316L
○ ○ ○
Process connection
C
JIS 10K
○ ○ ○
D
JIS 20K
○ ○ ○
E
JIS 30K
○ ○ ○
H
ASME 150
○ ○ ○
J
ASME 300
○ ○ ○
K
ASME 600
○ ○ ○
L
JPI 150
○ ○ ○
M
JPI 300
○ ○ ○
N
JPI 600
○ ○ ○
P
DIN PN 10
○ ○ ○
Q
DIN PN 16
○ ○ ○
R
DIN PN 25
○ ○ ○
S
DIN PN 40
○ ○ ○
Z
Other than above
○ ○ ○
Transmitter construction (※2)
1
Integrally mounted
○ × ×
2
Separately mounted
○ ○ ○
Power source
1
20 to 30VDC
2
85 to 264VAC (Safety rated 100 to 240VAC), 50/60Hz
Analog output (※3, 4, 5)
A
Output 1: Mass flow Output 2: Mass flow
B
Output 1: Mass flow Output 2: Density
C
Output 1: Mass flow Output 2: Temperature
D
Output 1: Mass flow Output 2: Volume flow (true density)
E
Output 1: Mass flow Output 2: Volume flow (fixed density)
F
Output 1: Density Output 2: Temperature
G
Output 1: Volume flow (true density) Output 2: Dens (true density)
H
Output 1: Volume flow (fixed density) Output 2: Density
J
Output 1: Volume flow (true density) Output 2: temperature
K
Output 1: Volume flow (fixed density) Output 2: Temperature
X
Non-output In the case of FOUNDATION fieldbus,PROFIBUS communication
Pulse output (※3, 4, 5)
A
Output 1: Mass flow
Single pulse
B
Output 1: Volume flow (true density)
C
Output 1: Volume flow (fixed density)
D
Output 1: Mass flow Output 2: Mass flow
Double pulse
E
Output 1: Mass flow Output2: Volume flow (true density)
F
Output 1: Mass flow Output2: Volume flow (fixed density)
G
Output 1: Vol. flow (true dens.) Output 2: Vol. flow (true dens.)
H
Output 1: Vol. flow (fixed dens.) Output 2: Vol. flow (fixed dens.)
J
Output 1: Volume flow (true dens.) Output 2: Mass flow
K
Output 1: Volume flow (fixed dens.) Output 2: Mass flow
X
Non-output In the case of FOUNDATION fieldbus,PROFIBUS communication
Pulse output type (※3)
0
Non-output In the case of FOUNDATION fieldbus,PROFIBUS communication
1
Open drain pulse (standard)
2
Voltage pulse
Communication interface
1
HART communication HART protocol version7、Bell202
2
FOUNDATION fieldbus H1 communication
(※3)
ITK version6
3
PROFIBUS PA communication
(※3)
Profile version3.02
4
Modbus communication RS-485 Modbus protocol
Explosionproof rating
0
Non-explosionproof
1
TIIS
2
ATEX, IECEx
3
KOSHA/KTL (※6)
4
CSA (※6, 7)
5
GOST
7
NEPSI (※6, 7)
In preparation
Explosionproof temperature class
0
Non-explosionproof
1
Sensor unit: Temp. class T1, separate transmitter only,
CA100 to CA150 (high temp. service model) only
2
Sensor unit: Temp. class T2，separate transmitter only
3
Sensor unit: Temp. class T3, separate transmitter only
4
Sensor unit: Temp. class T4
5
Sensor unit: Temp. class T5, (－200℃ to +50℃), Low temp. explosionproof service only
15.1.2 CA100 to CA250
NOTES
※1：Explosionproof specification has restrictions on temperature class.
※2：If temperature of the fluid exceeds 80℃, only "Separately mounted" type is available for the transmitter construction.
※3：When FOUNDATION fieldbus, PROFIBUS is selected for communication interface,
product code categories of analog output is "X" and pulse output is "X" (pulse output type:"0").
※4：When "Volume flow (fixed density)" is selected for analog output or pulse output, fixed density will be applied.
※5：Simultaneous output of both "Volume flow (fixed density)" and "Volume flow (true density)" for analog output and pulse
output is not available.
※6：Communication interfaces "FOUNDATION fieldbus H1 communication" and "PROFIBUS PA communication" are
unavailable. (in preparation)
※7：Models CA15H through CA250 are unavailable. (in preparation)
The new product code has been implemented since April 2017.
Therefore, the product code explanation of the old product code will not be updated after April 2017.
Contact OVAL for any inquiries about the old product code.
※:
