9.2.3 Transition chart of view (2)
MODE SELECT
Process screen
1.Password & Disp
2.Setup
1.Flow Param
2.Dens Param
1.Mass Unit
2.Vol Unit
3.Flow Damp
4.Flow Cutoff
1.Dens Compen
2.Std Temp
Exit Exit
3.Diag/Service
4.Maintenance
6.H/L Alarm
3.Exp Coef
4.Settled Dens
5.Dens Value
Exit
5.Flow Direct
Exit
1.Dens Unit
2.Dens Damp
3.Slug Low
4.Slug High
5.Slug Duration
Exit
6.Special Dens
1.Temp Unit
2.Temp Damp
Exit
5.Status Input
4.Outputs
3.Temp Param
： "SEL1" operation
： "SEL3" operation (For operating procedure, see 9.1.2 Switching operation.)
： "ENT" operation
※1
※1：For this function, the setting change is disabled in Write Protect mode (refer to section 9.2).
