No. Item Description Setup Default
1-1 Password Set
Selects password active/inactive. With "ON" selected, entering a password is requested before entering
setup menu screen from "MODE SELECT" screen. This prevents unauthorized password change.
For details of password, see 9.5 Password Function.
See 9.4 Off
1-2 Password
Sets a password. To validate the setting, password function in [No. 1-1] requires to be turned "ON".
A precaution to remember: If password is forgotten, there will be no way to change parameters.
See 9.3 9999
1-3-1 Var. Priority
Selects run indicator display/hide and priority of variables view.
For details, see 9.1.1 Variables view screen setup.
See 9.11
1-3-2 Refresh LCD
Changes LCD display refresh rate (ms). Select one from 1: 100ms, 2: 200ms, 3: 500ms, 4: 1000ms, or 5:
2000ms. Select a slower rate if the reading changes too fast, making it difficult to read; select a faster rate if
prompt readout is desired.
See 9.4 500ms
1-3-3 Font
Changes LCD font size.
1: Double angle ⇒ Larger font, allowing 2 variables view in one screen.
2: Normal ⇒ Smaller font, allowing 3 variables view in one screen.
See 9.4 Double
1-3-4-1 Mass Flow
Changes dcml pt. pos. in LCD instant mass rate. Select one that matches instant mass rate used. Select
from 1: Auto ⇒ Auto (from 5th dcml. plc. to no fractions, 2: Integer ⇒ No fractions, 3: 1st decimal ⇒ to 1st
dcml place, 4: 2nd decimal ⇒ to 2nd dcml plc., 5: 3rd decimal ⇒ to 3rd dcml plc., 6: 4th decimal ⇒ to 4th
dcml plc.
See 9.4 Auto
1-3-4-2 Vol Flow
Changes dcml pt. pos. in instant volume rate on LCD. Select one that matches instant mass rate used.
Select from 1: Auto ⇒ Automatic, 2: Integer ⇒ No fractions, 3: 1st decimal ⇒ to 1st dcml place, 4: 2nd
decimal ⇒ to 2nd dcml plc., 5: 3rd decimal ⇒ to 3rd dcml plc., 6: 4th decimal ⇒ to 4th dcml plc.
See 9.4 Auto
1-3-4-3 Density
Changes LCD decimal point position in density. Set to match the viscosity used. Selectable from 1: Auto ⇒
Automatic, 2: Integer ⇒ No fractions, 3: 1st Decimal ⇒ to 1st dcml place, 4: 2nd Decimal ⇒ to 2nd dcml
place, 5: 3rd Decimal ⇒ to 3 rd dcml place, 6: 4th Decimal ⇒ to 4th dcml place.
See 9.4 4th Decimal
1-3-4-4 Totalizer1
Changes LCD decimal point position in total flow 1. Set to match the total flow 1 used. Selectable from 1:
Auto ⇒ Automatic, 2: Integer ⇒ No fractions, 3: 1st Decimal ⇒ to 1st dcml place, 4: 2nd Decimal ⇒ to 2nd
dcml place, 5: 3rd Decimal ⇒ to 3rd dcml place, 6: 4th Decimal ⇒ to 4th dcml place.
See 9.4 Auto
1-3-4-5 Totalizer2
Changes LCD decimal point position in total flow 2 on LCD. Set to match the total flow 1 used. Selectable
from 1: Auto ⇒ Automatic, 2: Integer ⇒ fractions eliminated, 3: 1st Decimal ⇒ to 1st dcml place, 4: 2nd
Decimal ⇒ to 2nd dcml place, 5: 3rd Decimal ⇒ to 3 rd dcml place, 6: 4th Decimal ⇒ to 4th dcml place.
See 9.4 Auto
No. Item Description Setup Default
1-4 Back Light
Selects backlight mode. (In an erratic condition, it stays on or blinks depending on its nature.)
1: Off: Backlight stays off.
2: Sleep 5 min: Stays on for 5 min before it goes out.
3: Sleep 10 min: Stays on for 10 min before it goes out.
4: Sleep 20 min: Stays on for 20 min before it goes out.
5: Sleep 30 min: Stays on for 30 min before it goes out.
See 9.4
Sleep
20min
