Oval ALTI mass CA00A - 14.3 Type B

L
--
740
--
28
--
E
1
14.3 Type B
●
Main code
① ②
Model
C B ALTI mass Type B
③ ④ ⑤
Meter size/Nominal Diameter
JIS flange ASME•JPI flange Ferrule
0 0 6 10mm 1/2″ 10A
0 1 0 15mm 1/2″ 15A
0 1 5 15mm 1/2″ 15A
0 2 5 25mm 1″ 25 (ISO), IDF 1S
0 4 0 40mm 1·1/2″ 38 (ISO), IDF 1.5S
0 5 0 50mm 2″ 51 (ISO), IDF 2S
⑥ —
⑦
Fluid category
L Liquid
⑧
Temp. category ※1
1 Standard (130℃ and lower)
⑨
Major parts material
S SUS316L
⑩ ⑪
Process connection
J 1 JIS10K
J 2 JIS20K
J 3 JIS30K
A 1 ASME150
A 3 ASME300
A 6 ASME600
P 1 JPI150
P 3 JPI300
P 6 JPI600
H S ISO Ferrule
Z 9 Special
⑫ —
⑬
Explosion-proof
0 Non-explosionproof
1 TIIS ※2
2 ATEX/IECEx
3 KOSHA/KTL ※2
4 CSA (C-US) ※2
5 EAC ※2
7 NEPSI ※2
⑭
Ex-proof temp. class
0 Non-explosionproof
3 T3
4 T4
⑮
Regulations
0 Standard
H
High Pressure Gas Safety Act
(Individual test)
※w/Material test certicate
(Designed on PO issued)
J
High Pressure Gas Safety Act
(Completion inspection)
※w/Material test certicate
T Fire Service Act ※w/Material test certicate
S Ship Classication Society Pattern Approval
P Ship Classication Society Pattern Approval + w/Material test certicate
C CRN (Canadian Registration Number) Pattern approval ※3
K CRN (Canadian Registration Number) Pattern approval+w/Material test certicate ※3
F w/Material test certicate
⑯
—
⑰
Transmitter
1 ALTI mass
⑱
Transmitter construction ※4
1 Integrally mounted
2 Separately mounted
⑲
Power source
1 20 to 30VDC
2 85 to 264VAC (Safety rated 100 to 240VAC 50/60Hz)
⑳
Pulse
0 When "2, 3" are chosen for "Communication interface
󰼼
"
B Voltage pulse
G Open drain pulse (equivalent to open collector pulse) (standard)
󰼼
Communication interface
1 HART communication (HART protocol version 7, Bell202)
2 FOUNDATION Fieldbus H1communication (ITK version6)
3 PROFIBUS PA communication (Prole version3.02)
4 Modbus communication (RS-485 Modbus protocol)
󰽇
Version code
B Version code: B
󰽈 —
󰽉
Special shape designation
0 Standard
Z Special shape
※1: Explosionproof specications are restricted based on temperature class.
※2: "2, 3" for "Communication interface
󰼼
" are in preparation and is not available yet.
※3: CRN is applicable only to CSA explosionproof and ASME ange models.
※4: If temperature of the uid exceeds 80℃ for explosionproof types, only "Separately mounted" type is available for the transmitter construction.
In case of non-explosionproof, integral type can be used up to 130℃ by restricting the transmitter ambient temp. to 45℃ at max.
⑧⑦−⑤④③②① −⑮⑭⑬−⑪⑩⑨ ⑰ ㉒㉑⑳ ㉔−⑲⑱
Model
Temp. category
Meter size/Nominal Diameter
Fluid category
Power source
Transmitter construction
Transmitter
Regulations
Version code
Special shape designation
Communication protocol
Pulse
Ex-proof temp. class
Major parts material
Explosion-proof
Process connection
Main code
/ / / Additional code
