Oval ALTI mass CA00A - Titanium Tube Type

L
--
740
--
28
--
E
10
14.2.2 Titanium tube type
●
Main code
① ②
Model
C S
ALTI mass Type S
③ ④ ⑤
Meter size/Nominal Diameter
JIS flange ASME•JPI flange Ferrule
0 1 0 10mm 1/2″ 10A
0 1 5 15mm 1/2″ 15A
0 2 5 25mm 1″ 38 (ISO), IDF 1.5S
0 4 0 40mm 1·1/2″ 51 (ISO), IDF 2S
0 5 0 50mm 2″ 63.5 (ISO), IDF 2.5S
R 5 0 80mm 3″ 88.9 (ISO), IDF 3.5S
⑥ —
⑦
Density range
1
Low density liquids (0.5 to 1.0g/mL)
2
Ordinary density (0.7 to 1.3g/mL)
3
High density liquid (1.0 to 1.5g/mL)
⑧
Temp. category ※1
1
Standard (130℃ and lower)
⑨
Major parts material
T
SB338 Grade-9 + TB480H ※2
⑩ ⑪
Process connection
J 1 JIS10K
J 2 JIS20K
A 1 ASME150
P 1 JPI150
H S ISO Ferrule
Z 9 Special
⑫ —
⑬
Explosion-proof ※3
0 Non-explosionproof
1 TIIS
2 ATEX/IECEx
3 KCs ※4
4 CSA (C-US)
5 EAC ※4
7 NEPSI ※4
⑭
Ex-proof temp. class
0
Non-explosionproof
3
T3
4
T4
⑮
Regulations
0
Standard
E
EHEDG (CS025, CS040, CS050) + w/Material test certicate
T
Fire Service Act ※w/Material test certicate
S
Ship Classication Society Pattern Approval
P
Ship Classication Society Pattern Approval + w/Material test certicate
F
w/Material test certicate
⑯ —
⑰
Transmitter
1
ALTI mass
⑱
Transmitter construction ※5
1
Integrally mounted
2
Separately mounted
⑲
Power source
1
20 to 30VDC
2
85 to 264VAC (Safety rated 100 to 240VAC 50/60Hz)
⑳
Pulse
0
When "2, 3" are chosen for "Communication interface
󰼼
"
B
Voltage pulse
G
Open drain pulse (equivalent to open collector pulse) (standard)
󰼼
Communication interface
1
HART communication (HART protocol version 7, Bell202)
2
FOUNDATION Fieldbus H1communication (ITK version6)
3
PROFIBUS PA communication (Prole version3.02)
4
Modbus communication (RS-485 Modbus protocol)
󰽇
Version code
A
Version code: A
󰽈 —
󰽉
Special shape designation
0
Standard
Z
Special shape (including polishing, long neck)
※1: Explosionproof specications are restricted based on temperature class.
※2: If it is necessary to use the existing transmitter, consult OVAL.
※3: For CSR50, applicable explosionproof specications are TIIS, ATEX, and IECEx only.
※4: "2, 3" for "Communication interface
󰼼
" are in preparation and is not available yet.
※5: If temperature of the uid exceeds 80℃ for explosionproof types, only "Separately mounted" type is available for the transmitter construction.
In case of non-explosionproof, integral type can be used up to 130℃ by restricting the transmitter ambient temp. to 45℃ at max.
⑧⑦−⑤④③②① −⑮⑭⑬−⑪⑩⑨ ⑰ ㉒㉑⑳ ㉔−⑲⑱
Model
Temp. category
Meter size/Nominal Diameter
Density range
Power source
Transmitter construction
Transmitter
Regulations
Version code
Special shape designation
Communication protocol
Pulse
Ex-proof temp. class
Major parts material
Explosion-proof
Process connection
Main code
/ / / Additional code
