L
--
740
--
28
--
E
0
98
L
φ107
15
Rc1/4
Terminalbox
Cableentry G3/4
(G1/2 : TIIS)
Flow
direction
Flange
Ground
screw
Boss
H
h1
h2
W
A
98
L
15
Rc1/4
Flow
direction
Flange
Ground
screw
Groundscrew
Boss
H
h1
h2
W
5.1.8 Low temperature
explosionproof
service models (CA100 to CA250)
Dimensions in millimeters
Model
Flange
L H h1 h2 A W
App. Weight
kg（JIS 10K）
Nom. size Flange rating
CA100
(Low temp.
explosionproof
service models)
100
JIS 10K 992
1387 1015 660 300 810 231
JIS 20K 1006
JIS 30K 1016
4˝
ASME, JPI 150 1018
ASME, JPI 300 1036
ASME, JPI 600 1082
DN100
PN 10, 16 968
PN 25, 40 994
CA150
(Low temp.
explosionproof
service models)
150
JIS 10K 1300
1387 1015 660 300 810 246
JIS 20K 1320
JIS 30K 1330
6˝
ASME, JPI 150 1318
ASME, JPI 300 1338
ASME, JPI 600 1388
DN150
PN 10, 16 1250
PN 25, 40 1290
CA15H
(Low temp.
explosionproof
service models)
150
JIS 10K 1015
1588 1190 851 320 810 310
JIS 20K 1055
JIS 30K 1099
6˝
ASME, JPI 150 1087
ASME, JPI 300 1107
ASME, JPI 600 1157
DN150
PN 10, 16 1019
PN 25, 40 1059
CA200
(Low temp.
explosionproof
service models)
200
JIS 10K 1330
1588 1190 851 320 810 340
JIS 20K 1368
JIS 30K 1418
8˝
ASME, JPI 150 1418
ASME, JPI 300 1438
ASME, JPI 600 1494
DN200
PN 10, 16 1338
PN 25 1374
PN 40 1390
CA20H
(Low temp.
explosionproof
service models)
200
JIS 10K 1330
1814 1390 960 420 1110 610
JIS 20K 1368
JIS 30K 1418
8˝
ASME, JPI 150 1418
ASME, JPI 300 1438
ASME, JPI 600 1494
DN200
PN 10, 16 1338
PN 25 1374
PN 40 1390
CA250
(Low temp.
explosionproof
service models)
250
JIS 10K 1699
1814 1390 960 420 1110 650
JIS 20K 1743
JIS 30K 1805
10˝
ASME, JPI 150 1773
ASME, JPI 300 1805
ASME, JPI 600 1887
DN250
PN 10 1705
PN 16 1709
PN 25 1745
PN 40 1779
NOTE: Approximate weights in the table above are of JIS 10K.
For specifications of other flange ratings, see the approval drawing (or customer
,
s acceptance
specification).
Fig. 5.11 Outline Dimensions of Low Temperature Expiosionproof Sensor Unit (2/2)
(CA100 and 150) (CA15H to 250)
