15.3 Type B product codes
Item
Product Code
Description
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱
Model C B ALTImass Type B
Nominal size
0 0 6 10mm connection (3/8")
0 1 0 15mm connection (1/2")
0 1 5 15mm connection (1/2")
0 2 5 25mm connection (1")
0 4 0 40mm connection (1･1/2")
0 5 0 50mm connection (2")
Fluid category L Liquid service
Temp. category (※1) 1 Standard (below 125°C)
Pressure category 1 Standard
Major parts material S SUS316L
Process connection
B Ferrule
C JIS 10K
D JIS 20K
E JIS 30K
H ASME 150
J ASME 300
K ASME 600
T ASME 900
L JPI 150
M JPI 300
Z Other than above
Transmitter construction (※2)
1 Integrally mounted
2 Separately mounted
Power source
1 20 to 30VDC
2
85 to 264VAC
(Safety rated 100 to 240VAC)
, 50/60Hz
Analog output (※3, 4, 5)
A Output 1: Mass flow Output 2 : Mass flow
B Output 1: Mass flow Output 2 : Density
C Output 1: Mass flow Output 2 : Temperature
D Output 1: Mass flow Output 2 : Volume flow (true density)
E Output 1: Mass flow Output 2 : Volume flow (fixed density)
F Output 1: Density Output 2 : Temperature
G Output 1: Volume flow (true density) Output 2 : Density (true density)
H Output 1: Volume flow (fixed density) Output 2 : Density
J Output 1: Volume flow (true density) Output 2 : Temperature
K Output 1: Volume flow (fixed density) Output 2 : Temperature
X Non-output
In the case of FOUNDATION fieldbus,PROFIBUS communication
Pulse output (※3, 4, 5)
A Output 1: Mass flow
Single pulse
B Output 1: Volume flow (true density)
C Output 1: Volume flow (fixed density)
D Output 1: Mass flow Output 2 : Mass flow
Double pulse
E Output 1: Mass flow Output 2 : Volume flow (true density)
F Output 1: Mass flow Output 2 : Volume flow (fixed density)
G Output 1:
Vol. flow (true dens.) Output 2 : Vol. flow (true dens.)
H Output 1:
Vol. flow (fixed dens.) Output 2 : Vol. flow (fixed dens.)
J Output 1: Volume flow (true density) Output 2 : Mass flow
K Output 1: Volume flow (fixed density) Output 2 : Mass flow
X Non-output
In the case of FOUNDATION fieldbus,PROFIBUS communication
Pulse output type (※3, 4, 5)
0 Non-output
In the case of FOUNDATION fieldbus,PROFIBUS communication
1
Open
drain
pulse (standard)
2 Voltage pulse
Communication interface
1 HART communication
HART protocol version7、Bell202
2
FOUNDATION fieldbus H1 communication (※3)
ITK version6
3 PROFIBUS PA communication (※3)
Profile version3.02
4 Modbus communication RS-485 Modbus protocol
Explosionproof rating
0 Non-explosionproof
1 TIIS
2 ATEX, IECEx
3 KOSHA/KTL
(※6)
4 CSA
(※6)
5 GOST (※6)
7 NEPSI
(※6)
Explosionproof temperature class
0 Non-explosionproof
3 Sensor unit: Temp. class T3, separate transmitter only
4 Sensor unit: Temp. class T4
NOTES
※1：Explosionproof specification has restrictions on temperature class.
※2：If temperature of the fluid exceeds 80℃, only "Separately mounted" type is available for the transmitter construction.
※3：When FOUNDATION fieldbus, PROFIBUS is selected for communication interface,
product code categories of analog output is "X" and pulse output is "X" (pulse output type:"0").
※4：When "Volume flow (fixed density)" is selected for analog output or pulse output, fixed density will be applied.
※5：Simultaneous output of both "Volume flow (fixed density)" and "Volume flow (true density)" for analog output and pulse
output is not available.
※6：Communication interfaces "FOUNDATION fieldbus H1 communication" and "PROFIBUS PA communication" are
unavailable. (in preparation)
The new product code has been implemented since April 2017.
Therefore, the product code explanation of the old product code will not be updated after April 2017.
Contact OVAL for any inquiries about the old product code.
※:
