Oval ALTI mass CA00A - Transition Chart of View (3)

L
--
740
--
28
--
E

NOTE:
9.2.4 Transition chart of view (3)
MODE SELECT
Process screen
1.Password & Disp
2.Setup
1.Flow Param
1.Ana. Output1
Exit
Exit
6.H/L Alarm
2.Ana. Output2
Exit
3.Pls. Output1
5.Status Input
1.Assign
2.URV
3.LRV
4.Lowcut
5.Added Damp
Exit
1.Assign
2.URV
3.LRV
4.Lowcut
5.Added Damp
Exit
1.Assign
2.Freq Factor
3.Rate Factor
4.Lowcut
Exit
1.Assign
2.Freq Factor
3.Rate Factor
4.Lowcut
Exit
4.Maintenance
3.Diag/Service
6.Error Output
5.Status Output
4.Pls. Output2
2.Den Param
3.Temp Param
4.Outputs
： "SEL1" operation
： "SEL3" operation (For operating procedure, see 9.1.2 Switching operation.)
： "ENT" operation
※1
※1：For this function, the setting change is disabled in Write Protect mode (refer to section 9.2).
