Oval ALTI mass CA00A - CA006 Thru CA080 (Integrally Mounted Models)

L
--
740
--
28
--
E

A
W
L
φ134
h1
10
H
Groundscrew
Cableentry
G3/4
230
64
127
60
Flowdirection
5.1.2 CA006 thru CA080 (integrally mounted models)
Fig. 5.3 Outline Dimensions of Integrally Mounted Model (1/3)
Dimensions in millimeters
Model
Flange
L H h1 A W
App. Weight
kg (JIS 10K)
Nom. size Flange rating
CA006
10
JIS 10K 242
424 180 53 148 7
JIS 20K 242
JIS 30K 260
JIS 40K 260
JIS 63K 280
3/8˝
ASME, JPI 150 267
ASME, JPI 300 276
ASME, JPI 600 289
DN15
PN 10, 16 241
PN 25, 40 247
CA010
15
JIS 10K 256
462 218 53 163 7.8
JIS 20K 256
JIS 30K 276
JIS 40K 276
JIS 63K 294
1/2˝
ASME, JPI 150 282
ASME, JPI 300 291
ASME, JPI 600 303
DN15
PN 10, 16 256
PN 25, 40 261
CA015
15
JIS 10K 299
512 268 65 205 8.8
JIS 20K 299
JIS 30K 319
JIS 40K 319
JIS 63K 343
1/2˝
ASME, JPI 150 325
ASME, JPI 300 334
ASME, JPI 600 347
DN15
PN 10, 16 299
PN 25, 40 305
CA025
25
JIS 10K 380
580 329 83 262 13.3
JIS 20K 380
JIS 30K 400
JIS 40K 400
JIS 63K 422
1˝
ASME, JPI 150 411
ASME, JPI 300 424
ASME, JPI 600 437
DN25
PN 10, 16 376
PN 25, 40 380
NOTE: A pproximate weights in the table above are of JIS 10K.
For specifications of other flange ratings, see the approval drawing (or customer
,
s acceptance specification).
