■ Shipping Parameters
Given below is the explanation of parameters found in the parameter list attached to the product.
Continued on next page➡
No. Item Description Factory setting Setting
Device information
1 Tag Tag number (8-character)
2 Long Tag Tag number (32-character)
3 Descriptor Description
4 Message Message
5 Date Date of manufacture
6 Dev ID Device ID
7 Final asmbly num Final assembly number
8 Snsr s/n Sensor serial number
9 Snsr model Sensor model
10 Flange Flange rating
11 Snsr matl Sensor material
12 Hardware rev Hardware revision
Sensor type
13 Sensor type Sensor type
14 Mass flow USL Mass flow max. allowable range
15 Mass flow LSL Mass flow min. allowable range
16 Temperature USL Temperature max. allowable range
17 Temperature LSL Temperature min. allowable range
18 Vol flow USL Volume flow max. allowable range
19 Vol flow LSL Volume flow min. allowable range
20 Density USL Density max. allowable range
21 Density LSL Density min. allowable range
Flow
22 Mass flow unit Instantaneous mass flow unit
23 Vol flow unit Instantaneous volume flow unit
24 Flow direction Flow direction setting
25 Flow damp (Mass) Flow (Mass) damping
26 Flow cutoff Flow (Mass) cutoff
27 Vol flow coef Volume flow correction coefficient
Density
28 Unit Density unit
29 Damp Density damping
30 Slug low limit Lower density limit of gas multiphase flow detection
31 Slug high limit Upper density limit of gas multiphase flow detection
32 Slug duration Time duration of gas multiphase flow detection
33 Compensation Standard temp. compensation setting
34 Standard temp Standard temperature
35 Expansion coef Expansion coefficient
36 Settied density Fixed density compensation setting
37 Density Value Fixed density value
Temperature
38 Unit Temperature unit
39 Damp Temperature damping
Analog output 1
40 Assign Analog output 1 assignment
41 URV Analog output 1 setting at 20mA
42 LRV Analog output 1 setting at 4mA
43 Lowcut Analog output 1 low-cut
44 Added damp Analog output 1 added damping
Analog output 2
45 Assign Analog output 2 assignment
46 URV Analog output 2 setting at 20mA
47 LRV Analog output 2 setting at 4mA
48 Lowcut Analog output 2 low-cut
49 Added damp Analog output 2 added damping
