No. Item Description Factory setting Setting
Pulse output 1
50 Assign Pulse output 1 assignment
51 Freq factor Pulse output 1 full scale frequency
52 Rate factor Pulse output 1 full scale flow rate
53 Lowcut Pulse output 1 low cut
Pulse output 2
54 Assign Pulse output 2 assignment
55 Double pulse mode Double pulse output 2 assignment
56 Freq factor Pulse output 2 full scale frequency
57 Rate factor Pulse output 2 full scale flow rate
58 Lowcut Pulse output 2 low cut
Status input/output
59 Input function Status input function selection
60 Input mode Status input mode selection
61 Output function Status output function selection
62 Drive out point Drive output voltage threshold
63 Output mode Status output mode selection
H/L alarm
64 H/L alarm assign H/L alarm assignment
65 H/L alarm type H/L alarm type selection
66 High alarm point High alarm point
67 Low alarm point Low alarm point
68 H/L alarm hys H/L alarm hysteresis value
Error select
69 Sensor failure
Output selection for each item
70 Transmitter failure
71 Calibration failure
72 Saturated alarm
73 Parameter failure
74 Transmitter alarm
75 Slug flow alarm
76 Calibration in progress
77 Fixed output
Error output
78 Analog Analog output pattern on errors
79 Pulse Pulse output pattern on errors
Flow cal
80 SK20 Meter factor of flow rate
81 SKM Meter error correction item
82 SKt Flow correction coefficient (Skt)
83 Cal temp Flow calibration temperature
84 Cal temp (Outer) Flow calibration temperature
85 Cal freq Flow calibration frequency
86 SKdt Flow correction coefficient (Skdt)
87 SKfa Flow correction coefficient (Skfa)
88 SKfb Flow correction coefficient (Skfb)
89 FKt Flow correction coefficient (Fkt)
90 FKdt Flow correction coefficient (Fkdt)
Zero factor
91
Snsr zero value Sensor zero adjusting value
