Oval ALTI mass CA00A - Ferrule Fitting Type

L
--
740
--
28
--
E
1
A
φ134
230
64
127
60
Groundscrew
W
L
h1
10
H
φD
Cableentry
G3/4
Flowdirection
Ferrule
5.1.9 Ferrule fitting type (integrally and separately mounted models,
low temp. explosionproof service models)
●
Integrally mounted type
Dimensions in millimeters
Model
Ferrule fitting
L H h1 A W φD
App. Weight
kg
Nom. size Connection
CA006 10 Ferrule 10A 231.5 424 180 53 148 34 5.7
CA010 15 Ferrule 15A 256 462 218 53 163 34 6.3
CA015 15 Ferrule 15A 289 512 268 65 205 34 7.1
CA025 25
Ferrule 25 (ISO)
IDF 1S
370 580 329 83 262 50.5 10.7
CA040 40
Ferrule 38 (ISO)
IDF 1.5S
493 710 452 121 385
50.5
19
CA050 50
Ferrule 51 (ISO)
IDF 2S
64
CA080 80
Ferrule 76.1 (ISO)
IDF 13S
658.5 880 602 174 510 91 51
Process connection: A in mm; S (sanitary) in inches.
Fig. 5.12 Outline Dimensions of Integrally Mounted, Ferrule Type Sensor Unit
