Oval ALTI mass CA00A - Page 139

L
--
740
--
28
--
E
1
NOTES
※1: In case of CS080, the lower limit temp. is -20deg.C
※2: For CA00A, CA001,CA003 and CA High, Low Temp. service model,
only separate types are applicable.
※3: In case of CB006 to CB050, the upper limit temp. is +125deg.C
※4: In case of CS010 to CS080, the upper limit temp. is +130deg.C
SYSTEM BLOCK DIAGRAM (CONTROL DRAWING)
Fig.11.2
