No. Item Description Setup Default
3-4-1-1 4mA
Trims 4mA analog output 1. It is factory adjusted and normally further adjustment is not required.
However, if it is absolutely necessary, follow the procedure outlined.
For details, see 9.9 Analog Output Trim.
See 9.9 —
3-4-1-2 20mA
Trims 20mA analog output 1. It is factory adjusted and normally further adjustment is not required.
However, if it is absolutely necessary, follow the procedure outlined.
For details, see 9.9 Analog Output Trim.
See 9.9 —
No. Item Description Setup Default
3-4-2-1 4mA
Trims 4mA analog output 2. It is factory adjusted and normally further adjustment is not required.
However, if it is absolutely necessary, follow the procedure outlined.
For details, see 9.9 Analog Output Trim.
See 9.9 —
3-4-2-2 20mA
Trims 20mA analog output 1. It is factory adjusted and normally further adjustment is not required.
However, if it is absolutely necessary, follow the procedure outlined.
For details, see 9.9 Analog Output Trim.
See 9.9 —
No. Item Description Setup Default
3-5-1 Count/Total1
Resets counter 1 and totalizer 1 reading to 0.
For details, see 9.10 Reset Function.
See 9.10 —
3-5-2 Count/Total2
Resets counter 2 and totalizer 2 reading to 0.
For details, see 9.10 Reset Function.
See 9.10 —
No. Item Description Setup Default
4-1 Input Signals The screen is used for maintenance. View only —
4-2 View History
Shows the number of running hours of transmitter.
Can be switched to calendar view. (Incorporated clock is maintenance oriented; No updating takes place if
power to the transmitter is interrupted.)
—
4-3 Telop Info.
When the number of running hours exceeds 100,000, a black circle "●" begins to blink at lower left of LCD
which can be canceled.
1: Off ⇒ "●" stays off irrespective of elapsed hours. 2: ON ⇒ warning "●" begins to blink after 100,000
hours.
See 9.4 ON
4-4 Soft Version Shows the software version and checksum value. View only —
