12.2 I/O Allocation Table
Expression of numbers for input/output relays
Since input/output relays X and Y are handled in units of 16 points, they are expressed
as a combination of decimal and hexadecimal numbers as shown below.
Example: External input relay “X”
Decimal
1, 2, 3 12.....
Hexadecimal
0, 1, 2, 3 9 A,B F... ....
X0,X1 XF.....................
X 10, X 11 X 1F.....................
X 20, X 21 X 2F.....................
to to to
X 70, X 71 X 7F.....................
×
