Parker 690+ series User Manual

2-42 Parameter Specification
690+ Series Frequency Inverter
FRAME B - 230V Build Power Dependent Defaults
Single Phase Three Phase
Parameter Function Block Tag 0.75kW 1.5kW 2.2kW 0.75kW 1.5kW 2.2kW 4kW
DECEL TIME REFERENCE RAMP 259 10.0 10.0 10.0 10.0 10.0 10.0 10.0
DEFLUX DELAY PATTERN GEN 100 2.0 2.0 2.0 2.0 2.0 2.0 2.0
ENCODER INVERT FEEDBACKS 567 FALSE FALSE FALSE FALSE FALSE FALSE FALSE
ENCODER LINES FEEDBACKS 566 2048 2048 2048 2048 2048 2048 2048
ENCODER SUPPLY FEEDBACKS 761 10.0 10.0 10.0 10.0 10.0 10.0 10.0
FIXED BOOST FLUXING 107 0.00 0.00 0.00 0.00 0.00 0.00 0.00
INJ BASE VOLTS INJ BRAKING 739 100.0 100.0 100.0 100.0 100.0 100.0 100.0
INJ DC LEVEL INJ BRAKING 581 3.0 3.0 3.0 3.0 3.0 3.0 3.0
INJ DC PULSE INJ BRAKING 579 2.0 2.0 2.0 2.0 2.0 2.0 2.0
INJ DEFLUX TIME INJ BRAKING 710 0.5 0.5 0.5 0.5 0.5 0.5 0.5
INJ FINAL DC INJ BRAKING 580 1.0 1.0 1.0 1.0 1.0 1.0 1.0
INJ FREQUENCY INJ BRAKING 577 9.0 9.0 9.0 9.0 9.0 9.0 9.0
LEAKAGE INDUC MOTOR DATA 120 62.32 33.76 24.80 62.32 33.76 24.80 24.80
MAG CURRENT MOTOR DATA 65 1.36 2.50 3.41 1.36 2.50 3.41 5.84
MAX SPEED SETPOINT SCALE 1032 1500 1500 1500 1500 1500 1500 1500
MOTOR
CONNECTION
MOTOR DATA 124 STAR STAR STAR STAR STAR STAR STAR
MOTOR CURRENT MOTOR DATA 64 3.39 6.26 8.52 3.39 6.26 8.52 14.61
MOTOR POLES MOTOR DATA 84 4 4 4 4 4 4 4
MOTOR VOLTAGE MOTOR DATA 1160 230.0 230.0 230.0 230.0 230.0 230.0 230.0
MOTOR VOLTS VOLTAGE
CONTROL
122 230.0 230.0 230.0 230.0 230.0 230.0 230.0
MOTORING LIMIT SLIP COMP 85 150.0 150.0 150.0 150.0 150.0 150.0 150.0
MUTUAL INDUC MOTOR DATA 121 249.28 135.02 99.20 249.28 135.02 99.20 57.87
NAMEPLATE RPM MOTOR DATA 83 1400 1420 1420 1400 1420 1420 1420
OVERLOAD MOTOR DATA 1164 2.0 2.0 2.0 2.0 2.0 2.0 2.0
POWER MOTOR DATA 1158 0.75 1.50 2.20 0.75 1.50 2.20 4.00
POWER FACTOR MOTOR DATA 242 0.70 0.71 0.78 0.70 0.71 0.78 0.80
QUADRATIC
TORQUE
FEEDBACKS 50 FALSE FALSE FALSE FALSE FALSE FALSE FALSE
REFLUX TIME FLYCATCHING 709 3.0 3.0 3.0 3.0 3.0 3.0 3.0
REGEN LIMIT SLIP COMP 86 150.0 150.0 150.0 150.0 150.0 150.0 150.0
ROTOR TIME CONST MOTOR DATA 1163 109.40 136.75 136.75 109.40 136.75 136.75 136.75
SEARCH BOOST FLYCATCHING 32 40.0 40.0 40.0 40.0 40.0 40.0 40.0
SEARCH TIME FLYCATCHING 574 5.0 5.0 5.0 5.0 5.0 5.0 5.0
SEARCH VOLTS FLYCATCHING 573 9.0 9.0 9.0 9.0 9.0 9.0 9.0
SPEED INT TIME SPEED LOOP 1188 100 100 100 100 100 100 100
SPEED PROP GAIN SPEED LOOP 1187 20.00 20.00 20.00 20.00 20.00 20.00 20.00
STATOR RES MOTOR DATA 119 2.9367 1.5907 1.1687 2.9367 1.5907 1.1687 0.6817
SYMMETRIC TIME REFERENCE RAMP 267 10.0 10.0 10.0 10.0 10.0 10.0 10.0
TRIP THRESHOLD PWR LOSS CNTRL 1266 243 243 243 243 243 243 243
VHZ BASE FREQ FLUXING 106 50.0 50.0 50.0 50.0 50.0 50.0 50.0

Parker 690+ series Specifications

General

Frequency	50/60 Hz
Overload	150% for 60 seconds
Communication Options	Ethernet
Protection Rating	IP20
Operating Temperature	0°C to 55°C
Programmability	Yes
Communication Ports	RS485
I/O Capability	Digital and Analog I/O
Programming Languages	Function Block Diagram
Dimensions	Varies by module
