13.2 Communication with USB
By connecting the instrument and PC with USB cable, you can refer to information in the
internal memory and SD card. You can use this to transfer the file in the internal memory and
SD card to PC or send the file created in the PC to the internal memory or SD card.
Connect the instrument and PC by USB cable as follows;
[Connecting USB cable]
(1) Open the SD&USB slot cover.
(2) Insert the USB connector into the USB port in the right direction.
(3) After the USB cable is removed, close the SD&USB slot cover
completely.
CAUTION
• Be sure to open/close the SD&USB slot cover and insert/remove
the USB cable indoor.
Press [F3][USB] of the TRANSFER MENU screen
to view the DATA SAVE PLACE screen.
Select data save place, then press [ ENT].
[DATA SAVE PLACE]
INTERNAL
Refer to the internal memory of the instrument.
SD CARD
Refer to SD card.
[Button]
UPDATE
Reset USB communication and update the information being displayed on PC.
STOP
Finish USB communication, then return to TRANSFER MENU screen.
NOTE: If removable disk doesn’t activate although the USB is connected, click My
Computer then double-click Removable disk.
