138
1. Cylinder face
The Remote measurement is performed on the inner
surface of the vertical cylinder as shown left.
2. Fixed plane
The Remote measurement is performed on the fixed
plane, which is perpendicular to the sight of the
reference point as shown left.
3. Rotated plane
The Remote measurement is performed on the
Rotated plane, which is always perpendicular to the
present line of sight and induces the reference point
as shown left.
14.6 Compare method selection
Select 6.COMPARE METHOD SELECTION and
press [ENT] to view the COMPARE METHOD
selection window. Press [ENT] to select and press
[F5][ACCEPT].
When “ALL IN ONE INFO”is selected, all
information will be displayed on the result of
stakeout panel.
To Next Page
