Perfecta 115 TS - Page 33

Service Manual 4 Cutting Mechanism
4.2 Non-repeat device
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 33
PERFECTA Schneidemaschinenwerk GmbH  D-02625 Bautzen  Schäfferstr. 44  Tel.: +49-3591-556-131 to -133  Fax: +49 3591-556-139
Figure 25: PERFECTA 115/132 non-repeat device – seen from right.
2
Y 80
3
4
1
5
B 82
