Pin Configuration 121 May 03, 2004
Philips Semiconductors Preliminary User Manual
LPC2119/2129/2194/2292/2294ARM-based Microcontroller
98 I/O
P2.0 D0 External memory data line 0.
105 I/O
P2.1 D1 External memory data line 1.
106 I/O
P2.2 D2 External memory data line 2.
108 I/O
P2.3 D3 External memory data line 3.
109 I/O
P2.4 D4 External memory data line 4.
114 I/O
P2.5 D5 External memory data line 5.
115 I/O
P2.6 D6 External memory data line 6.
116 I/O
P2.7 D7 External memory data line 7.
117 I/O
P2.8 D8 External memory data line 8.
118 I/O
P2.9 D9 External memory data line 9.
120 I/O
P2.10 D10 External memory data line 10.
124 I/O
P2.11 D11 External memory data line 11.
125 I/O
P2.12 D12 External memory data line 12.
127 I/O
P2.13 D13 External memory data line 13.
129 I/O
P2.14 D14 External memory data line 14.
130 I/O
P2.15 D15 External memory data line 15.
131 I/O
P2.16 D16 External memory data line 16.
132 I/O
P2.17 D17 External memory data line 17.
133 I/O
P2.18 D18 External memory data line 18.
134 I/O
P2.19 D19 External memory data line 19.
136 I/O
P2.20 D20 External memory data line 20.
137 I/O
P2.21 D21 External memory data line 21.
Table 56: Pin description for LPC2292/2294
Pin
Name
LQFP144
Pin #
Type Description
