Pin Configuration 123 May 03, 2004
Philips Semiconductors Preliminary User Manual
LPC2119/2129/2194/2292/2294ARM-based Microcontroller
88 O
P3.1 A1 External memory address line 1.
87 O
P3.2 A2 External memory address line 2.
81 O
P3.3 A3 External memory address line 3.
80 O
P3.4 A4 External memory address line 4.
74 O
P3.5 A5 External memory address line 5.
73 O
P3.6 A6 External memory address line 6.
72 O
P3.7 A7 External memory address line 7.
71 O
P3.8 A8 External memory address line 8.
66 O
P3.9 A9 External memory address line 9.
65 O
P3.10 A10 External memory address line 10.
64 O
P3.11 A11 External memory address line 11.
63 O
P3.12 A12 External memory address line 12.
62 O
P3.13 A13 External memory address line 13.
56 O
P3.14 A14 External memory address line 14.
55 O
P3.15 A15 External memory address line 15.
53 O
P3.16 A16 External memory address line 16.
48 O
P3.17 A17 External memory address line 17.
47 O
P3.18 A18 External memory address line 18.
46 O
P3.19 A19 External memory address line 19.
45 O
P3.20 A20 External memory address line 20.
44 O
P3.21 A21 External memory address line 21.
41 O
P3.22 A22 External memory address line 22.
Table 56: Pin description for LPC2292/2294
Pin
Name
LQFP144
Pin #
Type Description
