AXC F 1050
126 / 140
PHOENIX CONTACT 107709_en_00
Vibration (storage/transport) 5g
Shock 30g, 11 ms period, half-sine shock pulse, in accordance with
IEC 60068-2-27
Shock (operation) 10g (bump endurance test in accordance with EN 60068-2-29)
Ambient conditions
Processor
Processor Altera Nios II 1x 100 MHz
Connection data
Designation Axioline F connector
Connection method Push-in connection
Conductor cross section solid/stranded 0.2 mm² ... 1.5 mm²
Conductor cross-section [AWG] 24 ... 16
Stripping length 8 mm
Axioline F local bus interface
Number of interfaces 1
Connection method Bus base module
Transmission speed 100 Mbps
Number of supported devices Max. 63
Service interface
Number of interfaces 1
Connection method Micro-USB type B
Bus system USB
Number of channels 1
Transmission speed Max. 115.2 kbps
Electrical isolation No
Ethernet interface
Number of interfaces 2
Connection method RJ45 socket
Bus system RJ45
Number of channels 2
Transmission speed 10/100 Mbps
System limits
Amount of process data Max. 4096 bits (Axioline F local bus (input))
Max. 4096 bits (Axioline F local bus (output))
Max. 32768 bits (per station)
