AXC F 1050
96 / 140
PHOENIX CONTACT 107709_en_00
8.4 PROFINET system variables
Table 8-3 lists the PROFINET system variables of the integrated PROFINET controller func-
tions.
Table 8-3 PROFINET system variables (PROFINET controller functions)
System variable Type Description
PNIO_SYSTEM_BF BOOL No connection to a configured PROFINET device
An error has occurred in the PROFINET network, i.e. a con-
nection could not be established to at least one configured
PROFINET device. This value is not set if the “Control BF” pa-
rameter was set to FALSE for a PROFINET device. The
PROFINET device has therefore been excluded from con-
nection monitoring.
PNIO_SYSTEM_SF BOOL Diagnostic alarm on a configured PROFINET device
At least one PROFINET device is indicating a system error
(diagnostic alarm or maintenance alarm). The error priority
can be taken from the PNIO_DIAG_AVAILABLE,
PNIO_MAINTENANCE_DEMANDED, and
PNIO_MAINTENANCE_REQUIRED variables.
PNIO_MAINTENANCE_DEMANDED BOOL Maintenance demand
At least one PROFINET device is indicating the “maintenance
demand” alarm (high-priority maintenance alarm) with an ac-
tive connection. The PROFINET device can be identified
using the RALRM diagnostic block.
PNIO_MAINTENANCE_REQUIRED BOOL Maintenance required
At least one PROFINET device is indicating the “maintenance
required” alarm (low-priority maintenance alarm) with an ac-
tive connection. The PROFINET device can be identified
using the RALRM diagnostic block.
PNIO_FORCE_FAILSAFE BOOL All PROFINET devices are prompted to set their configured
substitute values.
PNIO_CONFIG_STATUS WORD Configuration status of the PROFINET controller
PNIO_CONFIG_STATUS_READY BOOL This variable is set if the PROFINET controller was able to ini-
tialize correctly. No desired configuration has been loaded by
PC Worx Engineer yet.
PNIO_CONFIG_STATUS_ACTIVE BOOL This variable is set if the desired configuration for the
PROFINET controller has been loaded.
In this state, the PROFINET controller attempts to establish a
connection cyclically to all devices in the desired configura-
tion (under the PROFINET icon).
PNIO_CONFIG_STATUS_CFG_FAULT BOOL The desired PROFINET controller configuration has not been
applied due to a serious error.
In this case, please contact Phoenix Contact.
