AXC F 1050
32 / 140
PHOENIX CONTACT 107709_en_00
3.10 Interfaces
The following interfaces are available on the controller (see Figure 3-11):
Figure 3-11 Interfaces: (1) Ethernet, (2) service interface (Micro-USB type B)
(1) 2 x Ethernet X1/X2: 10/100 Base-T(X) (switched internally)
(2) Service inter-
face (Micro-
USB type B)
Currently without function
8482B007
1
2
