Starting up with PC Worx Engineer
107709_en_00 PHOENIX CONTACT 57 / 140
Once the configured controller has been assigned to an online device, you can connect
PC Worx Engineer to the controller:
• Double-click on the controller node in the “PLANT” area.
The controller editor group opens.
• Select the “Cockpit” editor.
• Click on the button to connect PC Worx Engineer to the controller.
The icon next to the controller node in the “PLANT” area indicates the connection was
successful.
Figure 6-10 Connection to the controller was established successfully
