Description of the AXC F 1050
107709_en_00 PHOENIX CONTACT 19 / 140
3.3.2 The AXC F 1050 as a PROFINET controller in a PROFINET
network
Figure 3-3 shows the example of an AXC F 1050 as a PROFINET controller in a PROFINET
network.
Figure 3-3 AXC F 1050 as a PROFINET controller
Key:
A AXC F 1050 PROFINET controller
B PROFINET device (in the example: PROFINET bus coupler with connected Axioline F
I/O modules)
For additional information on how to integrate the AXC F 1050 into a PROFINET network
as a PROFINET controller, please refer to Section 7.4.
