Phoenix Contact AXC F 1050 User Manual

AXC F 1050
86 / 140
PHOENIX CONTACT 107709_en_00
Use as additional memory The SD card is used as additional memory (see also Figure 7-6 on page 83) if:
– The SD card is inserted after starting up the controller
or
– You have selected the “Use SD card as additional memory” setting in
PC Worx Engineer.
Inserting/removing the SD
card
If you are using the SD card as additional memory, you can insert or remove the SD card
before startup and while the controller is operating.
PC Worx setting To use the SD card as additional memory, make the following setting in PC Worx Engineer:
• Double-click on the “MONA” node in the “PLANT” area.
The “Online Parameters” editor opens.
• Select the “External SD card” view.
Figure 7-8 “Online Parameters” editor, “External SD card” view, Use SD card as addi-
tional memory
• In the “Use of external SD card” drop-down list, select the setting “Use SD card as ad-
ditional memory”.
NOTE: Potential data loss
If you remove the SD card while read and/or write access to the SD card is active, this may
result in a loss of data.
• Only remove the SD card when it is not being accessed.
