Connecting and wiring hardware
107709_en_00 PHOENIX CONTACT 47 / 140
5.3 Connecting Ethernet
• Connect the Ethernet network to the RJ45 sockets.
Figure 5-6 Connecting Ethernet
• Use an Ethernet cable that at least meets the IEEE 802.3 CAT5 requirements.
• Observe the bending radii of the Ethernet cables used.
8482B008
