AXC F 1050
16 / 140
PHOENIX CONTACT 107709_en_00
PROFINET controller /
PROFINET device func-
tions
The PROFINET protocol can be used via the Ethernet interfaces of the controller. In this
case, the controller can be used as a PROFINET controller and/or PROFINET device, de-
pending on the configuration. It cannot be used as a PROFINET controller and device con-
currently.
Axioline F local bus An interface to the Axioline F local bus is provided on the bottom of the controller. Bus base
modules are used to carry the communications power and the bus signals from the control-
ler through the Axioline F station. A bus base module is supplied with the controller.
Up to 63 Axioline F modules can be connected to the controller. The maximum number of
modules that can be operated depends on the current consumption of the modules. The
total current consumption of all devices connected to the controller must not exceed the
maximum current that the controller supplies for the local bus.
Axioline F/
System and firmware
For system-specific information on the Axioline F system, please refer to the online help for
the PC Worx Engineer software and the “Axioline F: System and installation”
(UM EN AXL F SYS INST) and “Axioline F: Diagnostic registers and error messages”
(UM EN AXL F SYS DIAG) user manuals.
The user manuals can be downloaded at
phoenixcontact.net/products.
MRP The MRP Media Redundancy Protocol protocol can be used via the Ethernet interfaces of
the controller. The controller supports the MRP client function, which can be enabled or dis-
abled via PC Worx Engineer (see also Section 7.6 for more information). This function is
disabled by default. If the function is enabled, it remains enabled after the supply voltage is
switched off and on. If the controller has been reset to the default settings, the MRP client
function will also be disabled again. In a ring with Media Redundancy Protocol, maximum
switch-over times of up to 200 ms can be expected.
Parameterization memory
/ SD card
The controller has an internal parameterization memory. This memory can be used to store
programs and configurations which belong to your project, e.g. the visualization project. If
the internal parameterization memory is not large enough for your application program, the
controller can be operated using an SD card. The SD card is optional and not required to
operate the controller.
For additional information on how to integrate the AXC F 1050 as a PROFINET controller
or device, please see Section 7.4.
NOTE: Electronics may be damaged if overloaded
Observe the current consumption of each device when configuring an Axioline F station.
The current consumption is specified in each module-specific data sheet and may vary.
The possible number of devices that can be connected depends on the structure of the
Axioline F.
The SD card is not included in the scope of delivery of the controller.
• Only use a parameterization memory provided by Phoenix Contact (see Section “Or-
dering data” on page 129).
NOTE: Damage to the SD card after formatting
The SD card is already formatted and is intended for use with Phoenix Contact devices.
If you format the SD card, certain information on the SD card that is required for use with
Phoenix Contact devices will be lost. After formatting, you can no longer use the SD card
to operate the controller.
• Make sure that the SD card is not reformatted.
