Hunter-Pro Series & Captain 8 Installation Guide
No.
Terminal
Description/Connected accessories
10.
TMPR1/2
Tamper switche inputs. TMPR 2 input can instead serve as an input
for additional zone (#9). See section 3.8.1, on page 28.
11.
EGND
Earth ground terminal, is to be used in places with severe electrical
activity (abnormal levels of lightning or electrical discharge). Connect
the terminal to metal cold water pipe or AC power outlet ground.
When using PIMA’s transformer, earth ground is not required.
12.
LINE
Phone line input terminals
13.
SET
Answering machine, fax and telephone sets terminals
14.
AUDIO IN, OUT,
CONT
Input/output for the MIC-200 microphone, VU-20U
1
voice module,
GSM-200 cellular communicator & the SMS-100 module.
15.
SERIAL
Input for the net4pro network card, FSK radio transmitters and
“Smart Home” systems.
16.
Expansion Card
Connector for the OUT-1000 & EXP-PRO UNIV local expanders
17.
KEYPAD
Connector for Technician keypad
18.
TRANSMITTER
Connector for the GSM-200 cellular communicator, the TRV/TRU-
100 radio transmitters and the SMS-100 module.
 The GSM-200 and the SMS-100 modules cannot be
installed together!
 To connect a radio transmitter together with the
GSM-200, use a special cable (P/N 3411058).
19.
Backup battery
Detachable lead-acid backup battery connector.
The contacts are: Red: (+); Black (-)
See the next section for jump-starting with a battery.
Inverting the battery wires will damage the PCB!
20.
AC
Detachable AC transformer connector
21.
JP6
Sirens’ power source jumper - unregulated or battery
22.
JP11
EOL resistor loops jumper
2.2.1.1 Current limit thermal fuses
 F1: Detectors (750mA);
 F2, F3: Siren #1 and #2 (0.9A);
 F4: Keypads (750mA);
 F7: Battery charger protection (200mA);
 F5: PCB and battery high current Thermo-fuse (5A/250VAC) protection;
 F6: PCB AC short Thermo-fuse (3.15A/250V) protection.
1 Only one of the two devices can be connected at a time.
