Pima Hunter-Pro Series - System Tests and Diagnostics

72
Programming the System
Hunter-Pro Series & Captain 8 Installation Guide
Express menu
Details
Set the number of remote expanders
Set account 1 numbers for the phone and radio reports
Set CMS 1 protocol and radio station ('T')
…
Set up to 4 telephone numbers of the CMS #1.
Press the asterisk key for ‘+’, ‘*’, ‘#’ and ‘P’ (one second pause).
Set CMS 1 reports
Set CMS 1 test time (PSTN & radio) and test interval
Set CMS 1 radio test interval
Enter a new Installer code (4-6 digits). You must enter a code or
cancel this step by pressing [END].
6.14 Key 0 (zero): Tests
See the menu screens in section B.8, on page 101.
The Tests menu has sub-menus in which you can perform system tests of the hardwired and
wireless zones, the outputs and the communication channels.
6.14.1 Walk-Test
Test the hardwired and wireless zones, by walking and triggering the various detectors and
sensors. During the tests the number of successfully tested zones (out of the overall no. of
zones) is displayed.
The keypad buzzer will sound when a zone is opened. The "E-I" screen is for siren
indication, where:
a. ”E”: set to "+" to sound the external siren (the internal siren will sound too);
b. “I”: set to "+" to sound the internal siren only.
Parameter 'I' is not in use in Captain 8
When the tests are over, press [ENTR].
The memory log keeps a record of the tests with their results
If all zones were successfully tested the massage “All zones tested” is displayed. If not, the
zones that failed the test and their details are displayed as follows:
ENTR
1
Expanders
ENTER/NEXT/END
ENTRNEXT
Sys Installation
ENTER/NEXT/END

XMW
---
ENTR
Remote Expanders
0
3
ENTR ENTR
Communication
ENTER/NEXT/END
Account No.
ENTER/NEXT/END

NEXT
Acouont.No 1
Ph:0000 Rd:0000
Acouont.No 16
Ph:0000 Rd:0000
RadioTelephone
MS 1 Protocol
0 230 T= 0
ENTR NEXT
ENTR ENTR
Communication
ENTER/NEXT/END
Phone Numbers
ENTER/NEXT/END
MS Phone 1<Del=#
MS Phone 4<Del=#

X23
….
ENTR NEXT
ENTR ENTR
Communication
ENTER/NEXT/END
Phone Numbers
ENTER/NEXT/END
MS Phone 1<Del=#
MS Phone 4<Del=#

X23
….
AA12PFDMOLTWIR
+++++++++++-++1
Test Time:00:00
Interval:24 Hrs
Radio Tst. Inter
Hrs:24 Min.s:0
Installer Code
****** (4-6)
