Hunter-Pro Series & Captain 8 Installation Guide
Diagram 40. VU-20N/U two message connection diagrams
4.3.9 GSM-200 Cellular communicator
1. Connect the YELLOW wire to AUDIO IN.
2. Connect the ORANGE wire to AUDIO OUT.
Diagram 41. GSM-200 connection diagram
4.3.10 Backup Battery
See section 3.13, on page 35.
4.3.11 AC Power
See section 3.14, on page 35.
Control panel
VU-20U
YELLOW
BLUE
RED
BLACK
GREEN
M1 M2
GND
+12V
Audio
CONT
WHITE
Orange
Yellow
Control Panel
GSM-200
TRANSMITTER
OUT LINE
TELEPHONE
SET
AUDIO
IN
- -
