Pima Hunter-Pro Series - Captain 8 Wiring and Connections

38
CAPTAIN 8
Hunter-Pro Series & Captain 8 Installation Guide
No.
Terminal
Description/connected peripheral
transmitters and SMS-100 module.
 The GSM-200 and the SMS-100 cannot be installed
together!
 To connect a radio transmitter together with the
GSM-200, use a special cable (P/N 3411058).
13.
Backup battery
cables
The battery is a rechargeable lead-acid battery.
The contacts are: Red: Positive; Black: Negative.
See section 2.3 for battery jump-start.
Inverting the battery wires will damage
the PCB!
14.
AC
13.8v transformer input
15.
JP3 jumper
Is set according to the EOL loops (see section 4.3.3, on page 40)
4.2.1.1 Fuses
Fuse
Protects the...
F1
Siren power supply (0.9A)
F2
Keypads and detectors power supply (750mA)
F3
Battery
4.3 Connecting and Wiring
 The overall length of the wirings connected to the BUS cannot exceed 500
meters. If longer distance is required, see section 3.2.1, on page 15).
 The BUS uses PIMA proprietary protocol.
IMPORTANT! Disconnect all power supply before installation!
