Hunter-Pro Series & Captain 8 Installation Guide
3.2.7 I/O-16: remote 16 zone expander
Diagram 10. I/O-16 zone expander
RUN
MASTER DATA
FAIL
1 2 3 4 5 6 7 8 +
NC C NO
+
TMP
(-) (+) (IN)(OUT)
1 2 3 4
POWER SUPPLY
TECH KEYPAD
I/O-16
9 10 11 12 13 14 15 16
BUFFER
IN
ON
1 2 3 4
+ + + +
12V
Relay
Technician keypad
(-)
+12V
A buffer for extending the BUS over 500m
To external TAMPER switch
PS-2 Power supply input
TAMPER switch
3 (OUT)
4 (IN)
2 (+)
1 (-)
S C
JP1
(-)
Zone inputs, GND (-)
BUS
EOL loops jumper (KΩ ): S- 10/10, 10/13 C- 5.1/6.8
Parallel
connection
Card ID DIP switch
