Hunter-Pro Series & Captain 8 Installation Guide
6.10.2 The Output Types
In PIMA alarm systems, "Output Types" are detected events that are used for triggering the
physical outputs. Each output can be triggered by only one output type, whereas the same
output type can trigger as much as all the physical outputs.
The following table describes the output types and their triggers.
The event that triggers it
Zone alarm or system fault that are set to trigger the
"External Siren" output type as a response to alarm
Zone alarm or system fault that are set to trigger the
"Internal Siren" output type as a response to alarm
Alarm in a “Burglary” zone
Alarm in an “Anti-Mask” zone
Alarm in a “Special Burglary 1” zone
Alarm in a “Special Burglary 2” zone
Alarm in “Burglary”, “Special Burglary 1” or “Special
Burglary 2” zones
Alarm in a “Special Fire” zone
Alarm in a “Panic” zone, or pressing the panic key
combination [*]+[#].
Alarm in a “Silent Panic” zone
Alarm in a “Hold-Up (Duress)” zone, or entering
the “Duress” code
Alarm in a “Medical” zone
Triggering an audio module: MIC-200 or VU-20N/U
Opening a zone (regardless of the panel status)
Zone is bypassed by a user
Resetting smoke/fire detectors
Opening a tamper switch (connected via TMPR1/TMPR2
terminals)
Opening a zone tamper, or a zone failure
Activating the "Buzzer" output type
Arming the panel to any mode
Entering the Installer code
AC, Low battery or Phone line faults occur
Communication fault occurs
