Pima Hunter-Pro Series - Cellular Providers; The PSTN SMS Center Phones; Network Settings

Programming the System
61
Hunter-Pro Series & Captain 8 Installation Guide
6.6.2 Cellular providers
The parameters in this menu are described in the following table.
Parameter
Information to enter
Provider Name 1
User text
SMS center
phone 1
Enter a number only if it should be different from the one in the SIM
card
Provider APN…1
Enter the provider’s APN (Access Point Name). If the text is longer than
16 characters, press [ENTR] and continue to the next blank screen
Provider APN 1
Continue from previous screen
User…1
Enter the service's username. If the text is longer than 16 characters,
press [ENTR] and continue to the next screen.
User 1
Continue from previous screen
Password… 1
Enter the service's password. If the text is longer than 16 characters,
press [ENTR] and continue to the next screen
Password 1
Continue from previous screen
To set other providers, press [NEXT] in the “Cell. Providers1” screen.
6.6.3 The PSTN SMS center phones
Set the details for the SMS-100 PSTN module.
 SMS center OUT: the PSTN SMS center phone no. Usally already stored in the
SIM card.
 SMS center IN: not in use currently
6.6.4 Network settings
Set the system's network settings. It is recommend that the IP address will be static (fixed),
so communicating with it is easier. To use Static IP, fill in the address in the “STATIC IP”
screen; to use dynamic IP (DHCP) leave the “STATIC IP” address 0.0.0.0.
Setting MS1 & MS2 URL/IP and port is mandatory, when using either static or dynamic IP.
When using the net4pro-i (P/N 6247001) module, the URL/IP screens of
MS1 & MS2 must be left blank.
The network parameters are described in the following table.
