Pima Hunter-Pro Series User Manual

Introduction
7
Hunter-Pro Series & Captain 8 Installation Guide
1.3 Safety instructions
The Hunter-Pro 832/8144 and Captain 8 alarm systems have been registered in accordance with
EN60950 and its rules. EN60950 requires us to advise you the following information:
 Hazards of fire and electric shock exist in this alarm system. To reduce the risk of fire or
electric shock, do not expose this alarm system to rain or moisture. Pay attention: Telephone
cords could be a good conductor for lightings energy.
 Do not open the door of the alarm system. Dangerous high voltages are present inside of the
enclosure. Refer servicing to qualified personnel only.
 This alarm system should be used with 230VAC/110VAC, 50/60Hz, protected by anti-
electric shock breaker. To prevent electric shocks and fire hazards, do NOT use any other
power source.
 Do not spill liquid of any kind onto the unit. If liquid is accidentally spilled onto the unit,
immediately consult a qualified service.
 Install this product in a protected location where no one can trip over any line or power cord.
Protect cords from damage or abrasion.
 Disconnect all sources of power supply before proceeding with the installation. Pay
attention: do not install low voltage wires near any AC power wires. They should be
installed separately.
 Connect the AC transformer output to the terminal block on the control panel as marked.
 Connect the AC line cord to line power terminals as marked (GND; N; L).
1.4 Technical Specs
Hunter-Pro 832/8144
Captain 8
Input voltage
14VAC/2A
Battery
12VDC, Up to 7.5 Ah
Operating
temperatures (C)
Control panel: -10 ~ +50
LCD keypad: 0 ~ +50
LED keypad: -10 ~ +50
Protection
 Single or double EOL resistor circuits
 Continuous battery & telephone line monitoring
 DC sirens EOL resistor protection
Humidity
75% (non-condensed)
PCB outputs
 Relay: NO/NC 1A
 Open collector: 4, 100mA max
 Bell/Siren outputs: 2 with
separate thermal fuses
protection
 Open collector: 2, 100mA max
 Bell/Siren outputs: 1
 Serial output: RS-232
Communication
Channels
 PSTN: Telephone interface and communicator
 GSM: GSM-200 transmitter
 SMS: SMS-100 module (via PSTN)
 Ethernet: net4pro TCP/IP module
 Radio: TRV/TRU-100: long range VHF/UHF transmitters

Pima Hunter-Pro Series Specifications

General

Brand	Pima
Model	Hunter-Pro Series
Category	Security System
Language	English
