Programming the System
67
Hunter-Pro Series & Captain 8 Installation Guide
6.9 Key 6: System Responses
See the menu screens in section B.5, on page 99.
Set how the system will respond to the following events: Mains fault, Low Battery, Phone Line
fault, False Code and Zone Failure/Tamper.
Char.
Parameter
When setting to ‘+’:
S
Activate Siren
 While the panel is armed: the "External Siren" and "Internal
Siren" output types will be triggered;
 While the panel is disarmed: only the "Internal Siren" output
type will be triggered
S
Ext. SRN in OFF
While the panel is disarmed, the "External Siren" output
type will be triggered in alarm
A
Act. Burgl Output
The “Burglary” output type will be triggered in alarm
L
No daytime CMS
Reports to the Monitoring Station will be disabled while the
panel is disarmed
B
Activate Buzzer
The"Buzzer" output type will be triggered
6.10 Key 7: Outputs Configuration
See the menu screens in section B.6, on page 100.
Configure the control panel and the expanders’ outputs, i.e., set which output type will trigger
each output; see section 6.10.2, on page 79 on outputs and output types.
Outputs can be triggered per partition.
Hunter-Pro Series outputs
The Hunter-Pro series PCB has 7 outputs: SIRENS Ext. & Int., SMOKE, RELAY, ON/OFF,
ALARM, AUDIO CONT. The other screens in the menu are those of the OUT-1000 local zone
expander, the I/O-8N remote zone expander and the I/O-R relay expander.
Captain 8 screens
The Captain 8 PCB has 3 outputs: Siren, Smoke & PGM. The other screens are those of the
I/O-8N remote zone expander and the I/O-R relay expander.
6.10.1 How to configure a physical output?
The process of configuring an output goes as follows (see the next sections for full details):
1. Select a physical output;
2. Select the triggering output type;
3. Set the output’s partition/s;
4. Set the output’s polarity.
