4.6
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
EFI System Assembly View
1
Electronic Control Unit (ECU)
7
Fuel Pump / Regulator
2
Crankshaft Position Sensor (CPS)
8
Fuel Level Sender
3
Engine Coolant Temperature Sensor (ECT)
9
Fuel Filter
4
Dual Throttle Body Assembly
10
Fuel Supply Line
5
Fuel Injectors
11
T-MAP Sensor
6
Fuel Rail / Regulator
12
Electronic Throttle Control
FUEL SYSTEM
