9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
Relay Operation
Located in the fuse box under the dash, the relays assist
with component operation like the cooling fan, fuel pump
and EFI system, drive system and EPS.
NOTE: The Rear Diff Solenoid Relay (INT’L) is
mounted separately, attached to the lower airbox
bracket, accessed through the right rear wheel well.
The Headlight Relay (INT’L) and Flash to Pass Relay
(INT’L) are also mounted separately, located under
the dash.
CHASSIS RELAY provides power to the following
systems:
• Lights (Headlights / Taillights)
• Drive (AWD)
• Accessory (12V Receptacles / Accessory Options)
COLOR FUNCTION
Red
30-Amp fuse protected 12 Vdc
constant battery voltage.
Brown
Relay coil ground.
Orange
12 Vdc power input from key
switch to enable relay.
White
Provides 12 Vdc power for lights,
drive and accessory circuits.
EFI RELAY provides power to the following systems:
• Fuel Injectors
• Ignition Coil
• Fan Relay
• Fuel Pump Relay
COLOR FUNCTION
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Dark Green /
Yellow
ECU ground input to enable
relay.
Red / White
20-Amp fuse protected 12 Vdc
constant battery voltage.
Red / Dark Blue
Provides 12 Vdc power for EFI
system circuits.
FAN RELAY provides power to the following system:
• Fan Motor
COLOR FUNCTION
Red
20-Amp circuit breaker protected
12 Vdc constant battery power.
Orange / White
ECU ground input to enable
relay.
Red / Dark Blue
12 Vdc switched power from EFI
relay.
Orange / Black
Provides 12 Vdc power for fan
operation.
FUEL PUMP RELAY provides power to the following
system:
• Fuel Pump
COLOR FUNCTION
Red / Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green /
Yellow
ECU ground input to enable
relay.
Red / Dark Blue
12 Vdc switched power from EFI
relay.
Red / Blue
Provides 12 Vdc power for fuel
pump operation.
EPS RELAY (OPT) provides power to the following
system:
• Electronic Power Steering Unit
COLOR FUNCTION
Red
30-Amp fuse protected 12 Vdc
constant battery voltage.
Brown
Relay coil ground.
Orange
12 Vdc power input from key
switch to enable relay.
Orange
Provides 12 Vdc power for EPS
operation.
REAR DIFF SOLENOID RELAY (INT’L) provides power
to the following system:
• Rear Differential Solenoid
ELECTRICAL
