Polaris RZR XP4 1000 User Manual

2.28
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
2. Inspect all engine hoses for cracks, deterioration,
abrasion or leaks. Replace if necessary.
ITEM
DESCRIPTION
7
Bypass Hose
8
Waterpump Outlet Hose
9
Oil Cooler Inlet Hose
10
Oil Cooler Outlet Hose
3. Check tightness and condition of all hose spring
clamps. Replace if necessary.
Radiator Inspection / Cleaning
1. Check radiator air passages for restrictions or
damage.
ITEM
DESCRIPTION
1
Radiator
2
Shroud
3
Fan
2. Carefully straighten any bent radiator fins.
3. Remove any obstructions with low pressure
compressed air or low pressure water.
CAUTION
Washing the vehicle with a high-pressure washer could
damage the radiator fins and impair the radiators
effectiveness. Use of a high-pressure washer is not
recommended.
MAINTENANCE
