9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
COLOR FUNCTION
Red / Dark Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green /
White
ECU input to enable relay.
Brown
Relay coil ground.
Red
Relay switched power to operate
the Rear Diff Solenoid.
Blue
Ground to energize the Rear Diff
Solenoid.
HEADLIGHT RELAY (INT’L) provides power to the
following system:
• Headlights
COLOR FUNCTION
Red / Yellow
20-Amp fuse protected 12 Vdc
battery voltage.
White / Red
Key switch input to enable relay.
Brown
Relay coil ground.
Yellow / Dark
Green
Relay switched power to operate
the Headlights.
FLASH TO PASS RELAY (INT’L) provides power to the
following system:
• Momentary High Beam Headlight Operation
COLOR FUNCTION
Dark Green
12 Vdc switched power from
headlight relay used to operate
low beam headlights during
“normally closed” relay
operation.
Brown
Relay coil ground.
Yellow
High beam input to “open” relay
and disable low beam headlights
in order to operate high beam
headlights momentarily.
Dark Green
“Normally closed” relay output to
operate low-beam headlights.
ELECTRICAL
