9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
DIAGNOSTIC TROUBLE CODE TABLE
COMPONENT CONDITION SPN FMI P-CODE
Accelerator Position 2
Voltage Too High
29
3 P1228
Voltage Too Low
4 P1227
Not Plausible 2 P1225
Throttle Position Sensor 1
Voltage Too High
51
3 P0123
Voltage Too Low
4 P0122
Signal Out of Range
2 P0121
Vehicle Speed Signal
Data Erratic or Intermittent (or
missing)
84
2 P0503
Received Vehicle Speed Has Error
19 C1069
Accelerator Position 1
Voltage Too High
91
3 P0228
Voltage Too Low
4 P0227
Not Plausible 2 P0225
Manifold Absolute Pressure
Sensor (T-MAP)
Voltage Too High
102
3 P0108
Voltage Too Low
4 P0107
Intake Air Temperature (T-
MAP)
Voltage Too High
105
3 P0113
Voltage Too Low
4 P0112
Engine Temperature Sensor
(ECT)
Voltage Too High
110
3 P0118
Voltage Too Low
4 P0117
Temperature Too High
16 P0217
Engine Overheat Shutdown
0 P1217
System Power
(Battery Potential / Power
Input)
Voltage Too High
168
3
P0563
C1063
Voltage Too Low
4
P0562
C1064
Engine Speed (This is
applicable when the EPS
module gets the engine speed
from the ECM)
Error in Engine Speed
Computation
190
31 P121C
Received Engine Speed Has Error
19 C1066
Engine Speed
Error in Engine Speed
Computation
400 31 P121D
Gear Sensor Signal Voltage Too Low
523 4 P0916
ECU Memory
EEPROM: Read/Write Failure 628 12 C1073
Calibration Checksum/CRC Error 630 13 C1074
Crankshaft Position Sensor
(CPS)
Plausibility Fault
636 2 P0335
Camshaft Phase Sensor Circuit Fault 637 8 P0340
Injector 1 (MAG)
Driver Circuit Open / Grounded
651
5 P0261
Driver Circuit Short to B+ 3 P0262
Driver Circuit Grounded 4 P1262
Injector 2 (PTO)
Driver Circuit Open / Grounded
652
5 P0264
Driver Circuit Short to B+ 3 P0265
Driver Circuit Grounded 4 P1265
Rear Differential Output
Driver Circuit Open / Grounded
746
5 P1691
Driver Circuit Short to B+ 3 P1692
FUEL SYSTEM
